Features:
1. Versatility: The hydraulic hammer and the rotating head can be easily switched, covering almost all construction scenarios of photovoltaic power station construction. Hydraulic hammer: For pile driving, pile pulling Rotating head: For Ground screw piles, DTH drilling, Auger drilling
2.Mast: The effective stroke of the mast is 5m, plus a compensation height of 1m. The one-time propulsion stroke is 5.5m. This allows the YGL-600R-D to easily handle piling tasks below 6m, as well as drilling tasks below 5.5m.
3. Flexibility:The inner frame can extend horizontally by 50 cm. The mast can be adjusted horizontally from left to right 150mm. The luffing cylinder can sway by 10. The Max.forward tilt angle is 100°. So the vertical angle can be adjusted according to the ground.
4. 360° rotation: The slewing motor and slewing bearing adopt the well-known domestic hydraulic brand-Zhongyi. Construction workers can easily adjust the angle and direction of the ramming machine at the construction site to meet different operation requirements.
5. Tracks: Eddie Hydraulics is a well-known domestic hydraulic brand. Its hydraulic motors are reliable and durable. Customers report that there have never been any problems. Each track is 300mm wide and 700mm high. These precise dimensions enable it to easily cope with the most complex terrain. In addition to steel tracks, rubber tracks can also be customized, and rubber blocks can be added to the steel tracks (if used for highway guardrail construction, it can prevent damage to the highway).
6. Enlarge the hydraulic oil tank and diesel tank: the capacity is 140L. The hydraulic oil tank is equipped with a breathing valve to adjust the pressure and improve safety performance. Filters are installed at the oil outlet and inlet, which greatly prolongs the service life of the hydraulic oil.
Main parameters:
| Item | Value | Unit |
|---|---|---|
| Pile driving height | 6000 | mm |
| Ground screw installation height | 6000 | mm |
| DTH drilling depth | 5500 | mm |
| DTH drilling diameter | 50-350 | mm |
| Auger drilling depth | 5500 | mm |
| Transport dimensions (L×W× H) | 3640×1900×2580 | mm |
| Operating weight | 6800 | kg |
| Working platform turning angle | 360 | ° |
| Track plate width | 300 | mm |
| Track drive ratio | 1:21.4 | / |
| Climbing ability | ≤30 | ° |
| Rated power | 61 | kw |
| Hydraulic oil pump | 63 | ml/r |
| Hydraulic system pressure | 180 | bar |
| Hydraulic system flow | 138 | l/min |
| Torque of walking motor | 14100 | N·m |
| Walking speed | 0-3 | Km/h |
| Single impact energy of hydraulic hammer | 1260 | J |
| Mast left and right translation | 150 | mm |
| Drilling angle (right and left) | ±10 | ° |
| Drilling angle (anterior and backward ) | 35-100 | ° |
| Hydraulic oil tank capacity | 140 | L |
| Fuel tank capacity | 140 | L |
