Features:
1. Versatility: The hydraulic hammer and rotating head (hydraulic drilling motor) of the working accessories can be easily switched. They are specially designed for photovoltaic power station construction and can complete various complex working conditions such as pile driving, pile pulling / screw pile driving / auger drilling / impact drilling, which almost covers all construction scenarios in pile foundation construction in photovoltaic power station construction.
2. When YGL-600R is equipped with a hydraulic hammer, the distance from the bottom of the hydraulic hammer to the ground is 5.5m, so YGL-600R can handle pile driving work below 5.5m. When the rotating head is equipped, the effective stroke of the rotating head on the mast is about 5.0m, that is, the one-time propulsion stroke is 5.0m. Without connecting the drill rod, it can handle DTH drilling work below 5.5m and spiral drilling work below 5.0m.
3. The mast can be extended 40cm horizontally, with a maximum forward tilt angle of 100° and a luffing cylinder that can swing 10° left and right. This makes the YGL-600R more flexible, and the vertical angle can be adjusted according to the ground conditions, adapting to more complex working conditions.
4.360° rotation: The rotary motor and rotary bearing adopt the well-known domestic hydraulic brand - Zhongyi. The construction personnel can easily adjust the angle and direction of the drilling rig at the construction site to meet different operation requirements.
5. Tracks: The hydraulic motors of Eddie, a well-known domestic hydraulic brand, are reliable and durable, and customers have reported that there have been no problems. Each track is 2800mm long, 300mm wide, and 600mm high. These precise dimensions allow it to easily cope with the most difficult terrain. In addition to steel tracks, rubber tracks can also be customized, and rubber blocks can be added to steel tracks (if used in highway guardrail construction, it can prevent damage to the highway.
6. Hydraulic oil tank capacity: 105 liters. A breathing valve is installed on the top of the hydraulic oil tank to balance the air pressure inside the hydraulic oil tank. At the same time, it has excellent sealing performance to prevent the hydraulic oil from being contaminated and emulsified. The hydraulic oil can be used for a longer time and reduce costs.
7. Integrated operating table, one person can complete all operations of the machine.
8. Remote control system: Support customized remote control system. All operations can be completed by remote control, and the remote control distance is about 100m, which greatly reduces the difficulty of construction and improves construction efficiency.
Main parameters:
| Item | Value | Unit |
|---|---|---|
| Pile driving height | 5500 | mm |
| Ground screw installation height | 5500 | mm |
| DTH drilling depth | 5000 | mm |
| DTH drilling diameter | 50-350 | mm |
| Auger drilling depth | 5000 | mm |
| Auger drilling diameter | 50-400 | mm |
| Work dimensions (L ×W × H) | 4400×2585×7565 | mm |
| Transport dimensions (L×W× H) | 3640×1900×2580 | mm |
| Operating weight | 6300 | kg |
| Working platform turning angle | 360 | ° |
| Track plate width | 300 | mm |
| Track drive ratio | 1:21.4 | / |
| Climbing ability | ≤30 | ° |
| Rated power | 91 | KW |
| Hydraulic oil pump | 63+32 | Double-pump |
| Hydraulic system pressure | 200 | bar |
| Hydraulic system flow | 170 | l/min |
| Torque of walking motor | 7700 | N·m |
| Walking speed | 0-3 | Km/h |
| Single impact energy of hydraulic hammer | 1260 | J |
| Drilling angle (right and left) | 0-10 | ° |
| Drilling angle (anterior and backward ) | 0-100 | ° |
| Hydraulic oil tank capacity | ~105 | L |
| Fuel tank capacity | 85 | L |
